ASUS Mainboard PRIME H610M-E-CSM - micro ATX - LGA 1700 - Intel
Brand ASUS
New
In stock
Smart shoppers OnBuy it!
- Earn Cashback on every purchase – spend it instantly on your next order
- Free delivery – on millions of items across the site
- Customers love us – 131,000 Trustpilot reviews and an 'Excellent' rating
£119.32
FREE Delivery
1%
Earn £1.19 instantly
Learn More
Interest-free payment options available
See full product description & details
Delivery: Standard (Free) | Fri 21st - Thu 27th Aug
Returns: 30 days
180-day payment protection
You might also like
Description & Details
ASUS Mainboard PRIME H610M-E-CSM - micro ATX - LGA 1700 - Intel Description
ASUS Mainboard PRIME H610M-E-CSM - micro ATX - LGA 1700 - Intel
Details
| OPC | PCH8NFZ |
|---|---|
| Brand | |
| Codes | 4711387259795 (EAN) |
| Links | ASUS Motherboards |
External product information
Disclaimer: The information below is provided by various external sources and should be used as a guide only.
Detailed Product Information
Features
| Motherboard chipset | Intel H610 |
|---|---|
| Motherboard form factor | micro ATX |
| Audio output channels | 7.1 channels |
| Cooling type | Passive |
| Windows operating systems supported | Windows 10, Windows 11 |
| Power source type | ATX |
| Motherboard chipset family | Intel |
| Component for | PC |
Packaging data
| Package weight | 890 g |
|---|---|
| Package depth | 263 mm |
| Package height | 51.5 mm |
| Package width | 270 mm |
Processor
| Processor manufacturer | Intel |
|---|---|
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold |
| Processor socket | LGA 1700 |
| Supported processor sockets | LGA 1700 |
BIOS
| BIOS memory size | 128 Mbit |
|---|---|
| BIOS type | UEFI AMI |
Rear panel I/O ports
| PS/2 ports quantity | 2 |
|---|---|
| Line-in | Yes |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 1 |
| Microphone in | Yes |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Network
| Ethernet LAN | Yes |
|---|---|
| Wi-Fi | No |
| Ethernet interface type | Gigabit Ethernet |
| Top Wi-Fi standard | Not available |
Memory
| Maximum internal memory | 96 GB |
|---|---|
| Supported memory clock speeds | 4800,5000,5200,5400,5600 MHz |
| Supported memory types | DDR5-SDRAM |
| Memory channels | Dual-channel |
| Unbuffered memory | Yes |
| Memory slots type | DIMM |
| Number of memory slots | 2 |
| Supported memory clock speed (max) | 5600 MHz |
| ECC сompatibility | Non-ECC |
Weight & dimensions
| Width | 244 mm |
|---|---|
| Depth | 211 mm |
Packaging content
| Cables included | SATA |
|---|---|
| User guide | Yes |
Internal I/O
| USB 2.0 connectors | 2 |
|---|---|
| S/PDIF out connector | Yes |
| CPU fan connector | Yes |
| Number of COM connectors | 1 |
| ATX Power connector (24-pin) | Yes |
| Number of chassis fan connectors | 2 |
| Front panel audio connector | Yes |
| TPM connector | Yes |
| EPS power connector (8-pin) | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| Number of SATA III connectors | 4 |
| 12V power connector | Yes |
| RGB LED pin header | Yes |
Graphics
| Parallel processing technology support | Not supported |
|---|
Storage controllers
| Number of HDDs supported | 4 |
|---|---|
| Number of storage drives supported | 6 |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, SATA III |
Expansion slots
| PCI Express x1 (Gen 3.x) slots | 1 |
|---|---|
| Number of M.2 (M) slots | 2 |
| PCI Express x16 (Gen 4.x) slots | 1 |
