Color Sensor Recognition Module RGB Module IIC 2.54 Interface for Arduion Motherboard Compatible with LEGO B

Color Sensor Recognition Module RGB Module IIC 2.54 Interface for Arduion Motherboard Compatible with LEGO B Description

RGB color sensor recognition module for Arduino motherboards, IIC 2.54 interface, compatible with LEGO B series
This module primarily uses the TCS34725 color sensor. The TCS34725 is a low-cost, high-performance full-color RGB color recognition sensor. This sensor uses optical sensing technology to recognize the color of object surfaces, supports the three primary colors of red, green, and blue (RGB), supports light sensing, and can output corresponding specific values to help you reproduce true colors. This color-sensitive photodiode integrates a chip and a local infrared light-shielding filter to minimize the infrared spectral component in the incident light, thereby achieving more accurate color management. High sensitivity, wide dynamic range, and infrared light-shielding filter make the TCS34725 an ideal solution for color recognition of color-sensitive elements under varying lighting conditions and light attenuation. The TCS34725 color sensor has a wide range of applications, including RGB LED backlight control, solid-state lighting, health products, industrial process control, and medical diagnostic equipment. Operating voltage: 5V; Maximum power: 0.5W; Clock frequency: 0-400kHz; I2C address: 0x29; Current: 100mA; Detection distance: 3-10mm; Interface: IIC interface and 2.54mm pitch interface; Operating temperature: -10C to +50C. Specifications: B: With silicone housing; Color: As shown in the picture; Material: B: PCB + silicone. Package contents: 1 x Color recognition sensor. Only the above package contents are included; other products are not included. Note: Light reflection and different monitors may cause the color of the item in the picture to be slightly different from the actual item. Measurement tolerance is +/- 1-3 cm.
