DC Motor - DC 12V High Torque Worm Geared Motor Reduction Motor with Encoder Srong Self-locking(30RPM)

DC Motor - DC 12V High Torque Worm Geared Motor Reduction Motor with Encoder Srong Self-locking(30RPM) Description

Description: Gearbox output shaft direction of the motor shaft is arranged vertically, the entire body of the motor output shaft relative to the general direction of gear motor short, widely adapted to a number of installation dimensions of the requirement occasion. Specifications: Rated Voltage: 12V No-loading Revolving Speed: 100rpm / 40rpm / 30rpm / 20rpm / 10rpm(optional) Speed(rpm)10203040100Rated Torque(kg.cm)22.5127.45.61.5Max.Torque(kg.cm)252525246.4Reduction Ratio60034020015040No-load Current(MA)60Rated Current(A)0.6Stall Current(A)1.3 Weight: 165g(approx.) Wiring Methods: Red: Motor power + (exchange can control rotating and reversing) Black: Coding power- negative (3.3-5V) polarity cannot be wrong Yellow: Signal feedback Green:Signal feedback Blue:Coding power + positive(3.3-5V)polarity cannot be wrong White:Motor power - (exchange can control rotating and reversing) Package Includes: 1 x Motor Two-phase reduction gear motor with encoder Using precious metals carbon brush Long service life, low noise, large torque Stable and reliable performance Can rotate and reversal, work more accurate
