RF Power Amplifier Module 1-1000MHz 20dB 50Ω Low Noise
New
In stock
Smart shoppers OnBuy it!
- Earn Cashback on every purchase – spend it instantly on your next order
- Free delivery – on millions of items across the site
- Customers love us – 128,000 Trustpilot reviews and an 'Excellent' rating
£13.39
£19.41
31% off!
FREE Delivery
1%
What is instant Cashback?
Learn More
Interest-free payment options available
See full product description & details
Delivery: Standard (Free) | Tue 7th - Thu 9th Jul
Returns: 30 days
180-day payment protection
Most Popular in Radio Power Supplies
Description & Details
Summary
- Wide frequency range, stable gain and high amplifier output power +22dBm at1dBP.
- Especially suitable for various RF output stage circuits, convenient to use and with good performance.
- The power supply voltage of the module is DC 3.3-5.5V, and the system impedance is 50Ω.
- High safety factor, with strict quality control and quality assurance, can be used with peace of mind.
- Great workmanship, perfect replacement for the old one and has a long service life.
RF Power Amplifier Module 1-1000MHz 20dB 50Ω Low Noise Description
RF Power Amplifier Module Low Noise Electronic Component Board HMC580 Vpp=5V 50Ω
Item Type: RF Power Amplifier ModuleAmplifier Parameter Index:
Working Frequency: 1-1000MHz
Amplification Gain: 20dB (typical value)
Noise Figure: 2.8dB (typical value)
Amplifier Gain: As shown in the figure below
F= 5MHz, gain=24dB
F= 30Mhz, gain=23dB
F= 100MHz, gain=23dB
F= 150Mhz, gain=23dB
F= 420MHz, gain=21dB
F= 750MHz, gain=19dB
F=1000MHz, gain=17dB
Large Output Power: +22dBm (170mW) at 1dB compression point
Working Current: 88mA (5V)
Power Supply Voltage: 3.3-5.5V (DC)
System Impedance: 50Ω
