Selfsat Snipe Dome DRIVE-MN Full Auto Satellite GPS Tracking System

Selfsat Snipe Dome DRIVE-MN Full Auto Satellite GPS Tracking System Description

Enjoy your favourite satellite TV programs while driving with the Selfsat SNIPE DRIVE. Ideal for long journeys or when you are stuck in traffic. The annoying alignment at a new location is also no longer necessary. Thanks to the integrated GPS module and electronically controlled drive, the antenna is automatically aligned at the push of a button. You can receive your usual desired program even while the vehicle is in motion, as long as the respective satellite can be reached. Despite the small dimensions, the Selfsat SNIPE DRIVE offers a very good reception result.

The weight of the antenna is 15.5 kg and it can be mounted on any flat surface of the vehicle. Made from very durable material, the Selfsat antenna can be operated without any problems in the temperature range from -20°C to +60°C and permanently mounted on the vehicle.

Integrated GPS receiver

The Selfsat Snipe Dome has an integrated GPS receiver to determine the location faster when searching for satellites.

Auto tracking system

The implemented automatic tracking algorithm guarantees stable satellite transmission even during fast journeys

Dome design

The slim and aerodynamic design ensures low air resistance and thus less noise while driving.

Easy handling

Automatic alignment to the desired satellite (Astra1 / Astra2 / Hotbird) at the push of a button

Features:

• Integrated GPS receiver
• Automatic tracking algorithm
• IP System for streaming to portable devices
• Automatic positioner
• Pre-programmed satellites for a total of 8 satellites
• Finds the selected satellite within 1-2 minutes

Pre-Programmed Satellites:

• Astra 1 (19.2° East)
• Astra 2 (28.2° East)
• Astra 3 (23.5° East)
• Astra 4 (4.8° East)
• Hotbird (13° East)
• Thor (0.8° West)
• Eutelsat 5 West A (5° West)
• Eutelsat 9A (9° East)

Specifications:

LNB Type: Universal LNB
Antenna type: flat antenna
Output: 1
Frequency band: Ku band
Frequency range: 10.7 GHz to 12.75 GHz
LNB gain: 33.7 dB at 12.7GHz
Receiving power: 50 dB
Polarization: H / V
Tilt Angle: 15° ~ 65°
Search angle: 360°
Alignment time: 1-2 min.
Temperature range: -20°C to +60°C
Size (WxDxH) 700 x 700 x 315 mm
Weight: 15.5kg

What's included:

Selfsat Snipe DRIVE-MN
Control unit
1 m coaxial cable (for receiver)
17 m coaxial cable (for control unit)
Power supply cable
Screw set
Cable holder
Cable gland
Operation manual

Creative Satellite Ltd is a Direct Importer of Selfsat dishes and we only stock genuine Selfsat products.
