StarTech.com Dual mSATA SSD to 2.5â SATA RAID Adapter Converter Description
Vastly increase system performance by adding a dual mSATA SSD
RAID array into any 2.5" SATA HDD application with the 25SAT22MSAT
mSATA to SATA adapter.
Utilize the full potential of your SATA III controller, with mSATA
SSDs reducing your data transfer bottleneck with file transfer
speeds up to 6 Gbps. mSATA SSDs also save you money by reducing
your power consumption over regular platter drives.
You can achieve greater SSD capacity, or data redundancy with the
Dual SSD controller supporting multiple RAID modes (RAID 0, 1,
BIG). The SSD adapter also supports non-RAID operation (JBOD) when
paired with a port-multiplying SATA controller, so both drives can
be used independent of one another.
Help protect the health of your drive with an open-frame design
ensuring maximum heat dissipation.
The 25SAT22MSAT is backed by a StarTech.com 2-year warranty, and
lifetime technical support.
The StarTech.com Advantage
- Maximize system speed by adding SSD performance
- Achieve greater drive capacity, or secure data redundancy with
multiple RAID modes
- Reduce overall power consumption, with high efficiency mSATA
SSDs
Details
| OPC | PS2TJV |
|---|---|
| Brand | |
| Codes | 0065030855617 (EAN) |
Product Data
Ports & interfaces
| Output interface | mSATA |
|---|---|
| Internal | Yes |
| SATA revision | 3.0 |
| Host interface | SATA |
Technical details
| Plug and Play | Yes |
|---|---|
| Chipset | JMicron JMS562 |
| RAID levels | 0, 1, BIG, JBOD |
| Data transfer rate (max) | 6 Gbit/s |
Performance
| Port multiplier | Yes |
|---|---|
| Hot-swap | No |
| Plug and Play | Yes |
| Chipset | JMicron JMS562 |
| RAID levels | 0, 1, BIG, JBOD |
| Data transfer rate (max) | 6 Gbit/s |
| Product colour | Black,Green |
Design
| Mean time between failures (MTBF) | 5101299 h |
|---|---|
| Product colour | Black,Green |
| Certification | CE, FCC |
| RoHS compliance | Yes |
Certificates
| Certification | CE, FCC |
|---|---|
| RoHS compliance | Yes |
Colour
| Product colour | Black,Green |
|---|
Packaging data
| Package width | 170 mm |
|---|---|
| Package depth | 142 mm |
| Package height | 30 mm |
| Package weight | 108 g |
System requirements
| Windows operating systems supported | Yes |
|---|---|
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
Operational conditions
| Operating temperature (T-T) | -40 - 85 °C |
|---|
Weight & dimensions
| Width | 70 mm |
|---|---|
| Depth | 97 mm |
| Package width | 170 mm |
| Height | 7 mm |
| Package depth | 142 mm |
| Package height | 30 mm |
| Package weight | 108 g |
| Weight | 39 g |
Packaging content
| Mounting brackets included | Yes |
|---|---|
| Quick installation guide | Yes |
Other features
| Chipset | JMicron JMS562 |
|---|
Disclaimer: The information below is provided by various external sources and should be used as a guide only.
Detailed Product Information
Logistics data
| Master (outer) case height | 322 mm |
|---|---|
| Master (outer) case width | 382 mm |
| Master (outer) case length | 498 mm |
| Products per master (outer) case | 60 pc(s) |
| Harmonized System (HS) code | 84733020 |
Technical details
| Compliance certificates | RoHS |
|---|
