Description & Details
T1633MSC-B1 15.6IN BLACK 16:9 Description
T1633MSC-B1 15.6IN BLACK 16:9
Details
| OPC | PFYDZZC |
|---|---|
| Brand | |
| Codes | 4948570122523 (EAN) |
| Links | iiyama Monitors |
External product information
Disclaimer: The information below is provided by various external sources and should be used as a guide only.
Detailed Product Information
Display
| Pixel pitch | 0.179 x 0.179 mm |
|---|---|
| Contrast ratio (typical) | 1000:1 |
| Horizontal scan range | 30 - 68 kHz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Viewable size, horizontal | 34.4 cm |
| Viewable size, vertical | 19.4 cm |
| Display diagonal | 39.6 cm (15.6") |
| Display brightness | 385 cd/m² |
| Response time | 5 ms |
| Display resolution | 1920 x 1080 pixels |
| Display diagonal (metric) | 39.5 cm |
| Touchscreen | Yes |
| Maximum refresh rate | 60 Hz |
| Touchscreen technology | Projected capacitive system |
| Display technology | LCD |
| Number of simultaneous touchpoints | 10 |
| Native aspect ratio | 16:9 |
| HD type | Full HD |
| Panel type | IPS |
| Screen shape | Flat |
| Display number of colours | 16.7 million colours |
| Display brightness (typical) | 450 cd/m² |
| Response time measurement type | GTG (Gray to Gray) |
Other features
| Weight | 3.4 kg |
|---|---|
| Certification | CE, TÜV-Bauart, EAC, RoHS, ErP, WEEE, REACH, UKCA |
| User controls | Luminance (contrast, brightness, i-Style color, adv. contrast, overdrive), image setup (aspect ratio), color temp., OSD setup (H. position, V. position, timeout, language, touch wake up), extra (input select, DDC/CI, reset, opening logo, LED, volume, information) |
| AC adapter included | Yes |
| Height | 284 mm |
| Brightness | 385 cd/m² |
| Width | 389 mm |
| Depth | 200 mm |
| Control panel | Power, Menu, Volume +, Volume -, Input |
| Compatible operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| International Protection (IP) code | IP54 |
| Packaging content | AC adapter |
| USB ports quantity | 2 |
| Active display area (W x H) | 344.2 x 193.6 mm |
| Touch method | stylus, finger, glove (latex) |
| Compliance certificates | CE, EAC, REACH, RoHS, TÜV mark, UKCA, WEEE |
Power
| Power consumption (typical) | 12 W |
|---|---|
| Power supply type | External |
| AC adapter output voltage | 12 V |
| Power consumption (off) | 0.5 W |
| Power consumption (standby) | 8 W |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Energy efficiency scale | A to G |
| Energy efficiency class (SDR) | C |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 7.7 kWh |
| European Product Registry for Energy Labelling (EPREL) code | 1629639 |
Packaging data
| Package weight | 5.3 kg |
|---|---|
| Package depth | 169 mm |
| Package height | 343 mm |
| Package width | 475 mm |
| Package type | Box |
Ergonomics
| Cable lock slot | Yes |
|---|---|
| Height adjustment | No |
| Tilt angle range | 90 - 5° |
| On Screen Display (OSD) | Yes |
| Cable management | Yes |
| Panel mounting interface | 100 x 100 mm |
| On Screen Display (OSD) languages | Traditional Chinese, Czech, German, English, Spanish, French, Italian, Japanese, Dutch, Polish, Portuguese, Russian |
| Number of OSD languages | 12 |
| Tilt adjustment | Yes |
| Cable lock slot type | Kensington |
| VESA mounting | Yes |
Design
| Product colour | Black |
|---|---|
| Front bezel colour | Black |
Packaging content
| Cables included | AC, USB, HDMI |
|---|---|
| Quick start guide | Yes |
| Power adapter included | Yes |
Multimedia
| RMS rated power | 4 W |
|---|---|
| Built-in speaker(s) | Yes |
| Built-in camera | No |
| Number of speakers | 2 |
Ports & interfaces
| HDMI ports quantity | 1 |
|---|---|
| HDMI | Yes |
| HDCP | Yes |
| DisplayPorts quantity | 1 |
| Built-in USB hub | Yes |
| USB hub version | 2.0 |
| USB Touch port | Yes |
| Number of downstream ports | 2 |
Weight & dimensions
| Width (with stand) | 389 mm |
|---|---|
| Height (with stand) | 284 mm |
| Depth (with stand) | 200 mm |
| Weight (without stand) | 5.3 kg |
| Weight (with stand) | 3.4 kg |
Performance
| NVIDIA G-SYNC | No |
|---|---|
| AMD FreeSync | No |
| Palm rejection | Yes |
| Low Blue Light technology | Yes |
Sustainability
| Sustainability certificates | ErP |
|---|
Would you like us to let you know when it's back?
T1633MSC-B1 15.6IN BLACK 16:9
New
£572.39
