Product Images
TF1534MC-B7X 15" LCD 4:3 Projective Capa
Brand iiyama
New
In stock
Smart shoppers OnBuy it!
- Earn Cashback on every purchase – spend it instantly on your next order
- Free delivery – on millions of items across the site
- Customers love us – 126,000 Trustpilot reviews and an 'Excellent' rating
£483.60
FREE Delivery
1%
Earn £4.84 instantly
Learn More
Interest-free payment options available
See full product description & details
Delivery: Standard (Free) | Thu 11th - Fri 12th Jun
Sold by: LittleBigEssentialsLimited, there is 1 other seller
Returns: 30 days
180-day payment protection
Most Popular in Computer Monitors
Hot
Description & Details
TF1534MC-B7X 15" LCD 4:3 Projective Capa Description
IIYAMA TF1534MC-B7X 15 Inch 4:3Descriptioniiyama ProLite TF1534MC-B7X - LED monitor - 15" - open frame - touchscreen - 1024 x 768 - TN - 370 cd/m? - 700:1 - 8 ms - HDMI, VGA, DisplayPort - blackReviews
Details
| OPC | P7YXG5F |
|---|---|
| Brand | |
| Codes | 4948570118380 (EAN) |
| MPN | TF1534MC-B7X |
| Links | iiyama Monitors |
External product information
Disclaimer: The information below is provided by various external sources and should be used as a guide only.
Detailed Product Information
Display
| Pixel pitch | 0.297 x 0.297 mm |
|---|---|
| Contrast ratio (typical) | 700:1 |
| Horizontal scan range | 31.4 - 60 kHz |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 160° |
| Viewable size, horizontal | 30.4 cm |
| Viewable size, vertical | 22.8 cm |
| Display diagonal | 38.1 cm (15") |
| Display brightness | 330 cd/m² |
| Response time | 8 ms |
| Display resolution | 1024 x 768 pixels |
| Display diagonal (metric) | 38 cm |
| Touchscreen | Yes |
| Touch technology | Multi-touch |
| Touchscreen technology | Projected capacitive system |
| Touchscreen type | Multi-user |
| Display technology | LED |
| Number of simultaneous touchpoints | 10 |
| Native aspect ratio | 4:3 |
| HD type | XGA |
| Panel type | TN |
| Screen shape | Flat |
| Display number of colours | 16.2 million colours |
| Surface hardness | 7H |
| Display brightness (typical) | 370 cd/m² |
Other features
| Weight | 2.7 kg |
|---|---|
| Display viewable area (HxV) | 304 x 228 mm |
| User controls | picture (contrast, brightness, H.position, V.position, phase, clock, auto adjust), advanced (color temp., sharpness), OSD (time out, position, H-position, V-position, Touch switch), option (reset, language, source select, display mode, factory) |
| AC adapter included | Yes |
| Height | 265.5 mm |
| Brightness | 330 cd/m² |
| Width | 337.5 mm |
| Depth | 44.5 mm |
| Control panel | Menu, Scroll up/ Brightness, Scroll down/ Contrast, Select, Power |
| Compatible operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| International Protection (IP) code | IP65 |
| Packaging content | AC adapter |
| Active display area (W x H) | 304 x 228 mm |
| Touch method | stylus, finger, glove (latex) |
| Compliance certificates | CE, cULus, EAC, REACH, RoHS, WEEE |
Power
| Power consumption (typical) | 9 W |
|---|---|
| Power supply type | External |
| AC adapter output voltage | 12 V |
| Power consumption (off) | 0.3 W |
| Power consumption (standby) | 1.5 W |
| Energy efficiency scale | A to G |
| Energy efficiency class (SDR) | E |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 10 kWh |
Logistics data
| Products per pallet | 78 pc(s) |
|---|---|
| Harmonized System (HS) code | 85285210 |
| Pallet net length | 198.7 cm |
| Pallet net width | 91 cm |
| Pallet net height | 114 cm |
Packaging data
| Package weight | 4 kg |
|---|---|
| Package depth | 165 mm |
| Package height | 335 mm |
| Package width | 435 mm |
Ergonomics
| Wall mountable | Yes |
|---|---|
| On Screen Display (OSD) | Yes |
| Panel mounting interface | 100 x 100 mm |
| On Screen Display (OSD) languages | Traditional Chinese, German, English, Spanish, French, Italian, Japanese |
| Number of OSD languages | 7 |
| VESA mounting | Yes |
Design
| Product colour | Black |
|---|---|
| Front bezel colour | Black |
Packaging content
| Cables included | AC, USB, HDMI, DisplayPort |
|---|---|
| Quick start guide | Yes |
Ports & interfaces
| VGA (D-Sub) ports quantity | 1 |
|---|---|
| HDMI ports quantity | 1 |
| HDMI | Yes |
| HDCP | Yes |
| DisplayPorts quantity | 1 |
| USB Touch port | Yes |
Weight & dimensions
| Width (with stand) | 337.5 mm |
|---|---|
| Height (with stand) | 265.5 mm |
| Depth (with stand) | 44.5 mm |
| Weight (without stand) | 2.7 kg |
| Height (without stand) | 265.5 mm |
| Width (without stand) | 337.5 mm |
| Depth (without stand) | 44.5 mm |
| Weight (with stand) | 2.7 kg |
Performance
| NVIDIA G-SYNC | No |
|---|---|
| AMD FreeSync | No |
| Palm rejection | Yes |
Sustainability
| Sustainability certificates | ErP |
|---|
