Tp-Link EAP235-WALL Omada Ac1200 Wireless Wall Mount Access Point Dual Band EAP235-WALL

Tp-Link EAP235-WALL Omada Ac1200 Wireless Wall Mount Access Point Dual Band EAP235-WALL Description

  Omada AC1200 Wireless MU-MIMO Gigabit Wall Plate Access Point

Fast Dual-Band Wi-Fi: Simultaneous 300 Mbps on 2.4 GHz and 867 Mbps on 5 GHz totals 1,167 Mbps Wi-Fi speeds with MU-MIMO.
Four Gigabit Ports: 4 Gigabit Ethernet ports (1 uplink + 3 downlink), with one downlink port supporting PoE pass-through to provide power for wired device.
Integrated into Omada SDN: Zero-Touch Provisioning (ZTP), Centralized Cloud Management, and Intelligent Monitoring.
Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
Elegant Appearance: Ultra slimmest and conspicuous design blends into hotel rooms, hospitals, offices, dormitories and any other environments.
Easy Installation and PoE Support: Easy-mount construction, compatible with 86 mm & EU & US standard junction box, and 802.3af/at PoE support.
Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.
Advanced Wireless Tech: Optimize network performance with MU-MIMO, Band Steering, and Beamforming technologies.

Dedicated Complete, Private Wi-Fi Network in Each Room

An EAP in each room allows guests to enjoy their own private Wi-Fi network that's fast, delivering a strong signal, and providing corner to corner coverage.





MU-MIMO + Dual-Band: Connect Faster and More

802.11ac wave 2 MU-MIMO technology enables multiple users to access the Internet simultaneously, which largely boosts up your network speed of up to 1,200 Mbps. Capable of transmitting in both 2.4 GHz and 5 GHz wireless band, it provides greater compatibility to connect varieties of devices.





Absolute Thinnest, Inconspicuous Design

The thinnest wall plate AP available-only 15 mm-featuring a sleek, minimalist appearance. Designed to blend in with the decor of hotel rooms, hospitals, offices and school dormitories, to deliver powerful Wi-Fi without clashing with the room.





Effortless Deployment with PoE Powered

With 802.3af/802.3at Power over Ethernet supported there's no need to install additional wiring in the building. Simply plug in existing Ethernet cables and you're ready to go.





Quick, Simplified Installation

EAP235-Wall is easy to install, so extra cost, time, or professional knowledge are completely unnecessary.





Full Gigabit Ports to Bridge Network

Equipped with four Gigabit data ports (1*uplink + 3*downlink), one downlink port offering PoE pass-through, to connect multiple devices to your gigabit network. Wired devices like VoIP phones can be powered with no need for extra electrical cables.





Omada SDN-Smarter Cloud Solution for Business Networking

Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches and gateways, guaranteeing powerful business network with higher efficiency, higher security, and higher reliability.





Easy Management with the Omada App

Follow configuration instructions on the Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.

DescriptionSpecification

Primary Function: Access Point
#Hide#Access Point Mode: Yes (Access Point Mode)
Max Signal Rate: 867 Mbps
Dual Band: Yes
Interface(s): Uplink: 1 x 10/100/1000 Mbps Ethernet Port

Downlink: 3 10/100/1000 Mbps Ethernet Ports (One port supports PoE OUT. The PoE OUT feature requires 802.3at PoE+ input and the maximum output is 13 W.)
Wireless Standards: IEEE 802.11a/b/g/n/ac
Antenna: 2 x Dual-Band Antennas
2.4 GHz: 2 4 dBi
5 GHz: 2 4 dBi
Button(s): Reset
Power Supply: 802.3af/802.3at PoE
Power Consumption: 9.8 watts /24.4 watts (PoE Out Included)
Dimensions (W x D x H): 143 x 86 x 20 mm
Weatherproof: No
Frequency: 2.4 GHz and 5 GHz
Wireless Functions: 16 SSIDs (8 SSIDs on each band)
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control
QoS(WMM)
MU-MIMO
Band Steering
Beamforming
Load Balance
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client
Wireless Security: "Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Local LAN port based VLAN
Rogue AP Detection
802.1X Support
64/128/152-bit WEP, WPA/WPA2-PSK, WPA/WPA2-Enterprise"
Quality of Service: Yes
Management: "Omada App
Centralized Management
Cloud Access
Email Alerts
LED ON/OFF Control
Management MAC Access Control
SNMP v1,v2c
Local/Remote Syslog
SSH
HTTP/HTTPS
L3 Management
Multi-site Management
Management VLAN"
Advanced Functions: See Overview
Environment (C): Operating Temperature: 0C
40C (32F4F)
Storage Temperature: -40C
70C (-40F8F)
Operating Humidity: 10%
90% non-condensing
Storage Humidity: 5%
90% non-condensing
Package Contents: Omada AC1200 Wall Plate Access Point
Installation Guide
Mounting Screw
Package Type: Retail
Warranty: Limited Lifetime
