DMX302 DMX triac dimmer led brightness controller AC90-240V TRIAC 3-Ou

DMX302 DMX triac dimmer led brightness controller AC90-240V TRIAC 3-Ou Description

Description:

DMX triac dimmer adopts industrial grade advanced computer control chip, the shell adopt guide rail type, suitable for industrial environment

Increase 3 channels relay power supply output, adopts high-voltage MOS transistor as the control circuit to achieve trailing edge dimming.

It is used for controlling a variety of lamps which connects with triac power supply, and also can be connected with high-voltage LED load light

It has many advantages such as convenient to connect, easy to use and others. According to customer's actual demand can realize the dimming function.

Suitable for Industrial Environment, it can be directly connected to the lighting load

Specification:

Working temperature: -20-60

Supply voltage: AC90240V（5060Hz）

Output: 3 channels

External dimension: L87W72H54 mm

Static power consumption: <3W

Output current: <1A （each channel）

Output power: 110V: <3110W, 220V: <3220W

Diming method: trailing edge dimming

Package Includes:

1 Piece Light dimming driver
