RF Wide Band Amplifier Module 5V Low Noise, 18dB Gain, 0.6dB NF
New
Hurry only 1 left
Smart shoppers OnBuy it!
- Earn Cashback on every purchase – spend it instantly on your next order
- Free delivery – on millions of items across the site
- Customers love us – 129,000 Trustpilot reviews and an 'Excellent' rating
£16.00
£20.25
21% off!
FREE Delivery
1%
What is instant Cashback?
Learn More
Interest-free payment options available
See full product description & details
Delivery: Standard (Free) | Fri 24th - Mon 27th Jul
Returns: 30 days
180-day payment protection
Most Popular in Radio Power Supplies
Description & Details
Summary
- RF wideband amplifier is with wide frequency range, high gain, low noise figure.
- Have 0.6dB typical noise factor, 19dB typical gain, 23dB P1dB, provide stable performance.
- Can be used for high dynamic range receiver LNA application, and amplify small signal of 110dBM,
- You can cascade several LNA modules in order to improve gain, easy and convenient to use.
- Widely used for high frequency or intermediate frequency preamplifier of radio receiver, high sensitivity amplifying circuit of electronic detection equipment.
RF Wide Band Amplifier Module 5V Low Noise, 18dB Gain, 0.6dB NF Description
RF Wide Band Amplifier High Gain Low Noise LNA Module Board NF=0.6dB 5V
Item Type: RF Wide Band Amplifier
Voltage: 5V
Current: 90mA
Gain: 18dB at 0.9G
Input/Output Impedance: 50Ω
Maximum. Output Power: P1db 22dBm( at 2GHz)
Input Signal: <+10dBm (as low as -110dBm. If input>+10dBm, output distortion)
Bandwidth 0.05-4GHZ (different frequencies are different, refer to S21 curve)
Noise Figure: 0.6dB at 0.9GHz
Details
| OPC | PQ5NZQ9 |
|---|---|
| Codes | 4621377701442 (EAN) |
